Precision Sealing for High-Tech and Food Industries
Safely package sensitive electronics and perishable foods with this robust stainless steel impulse sealer. It provides precise temperature control, an integrated parameter alarm, and consistent 8mm seals via pneumatic bi-active seal bars.
The "open head design" streamlines operation, while the Audion Touch Techware with Audion Temperature Controller (ATC) ensures optimal product safety and seal quality.
Integrated vacuum & gas flush system with low maintenance Venturi pump, reduces volume, prevents oxidation extending shelf-life.
Manufactured in the Netherlands
Specifications
| Product Code | VAC PSR TC 520 |
| Seal Length | 520mm (720mm & 1020mm options) |
| Seal Width | 8mm (5mm & 10mm options) |
| Seal Type | Temperature controlled impulse seal |
| Validation | .csv file record: machine id, login level, recipe name, batch number, parameter settings, temperature tolerance, alarm limits, date/time, seal id, parameter results, pass/fail. alarm code |
| Digital Control | Audion Touch Techware control panel upto 50 recipes on seal temperature, cool temperature, seal time. Monitored seal temperature tolerance with alarm stop function. |
| Air Pressure | Requires: Min. 6 Bar, Max. 10 Bar |
| Operation | Pedal |
| Housing | Stainless Steel |
| Film Types | PE (Polyethylene), Aluminum Laminated Bags |
| Film Thickness | 2x 200 micron |
| Pump | Venturi 10m³/h |
| Classifications | Compatible with EN 60204-1 and fully complies to ISO 12100, ISO 4414 and ISO 14118. |
| Options Include | Automatic vacuum height adjustment, cutting device, digital vacuum flow regulator, ESD, E-Stop, external pump & exhaust, manual vacuum flow, powder filter, particle ejection system, quick cleaning system, silicone poor (SILA), water cooling seal bars, water separation, 20m³/h Venturi pump. |
| Accessories |
Industrial Support Frame, Motorized Support Frame, Cleanroom-friendly white polyamide wheels, stainless steel roller conveyor, bag support (adjustable in height), work table (adjustable in height); Label printer for printing the result of seal parameters on a label (Includes print signal and software). Wearing Parts (Seal wire (10 pcs), Upper PTFE (10 pcs), Lower PTFE (6 pcs), Silicone rubber red (6 pcs) Vacuum rubber (2 pcs), Audio-cone (1 pc)) |
This machine is custom-configured and manufactured to order. As it is not held in stock, please contact us to confirm current lead times.
